Milesight MS-C5341-X30PC - Page 56

50
User Name
User name used to log in to the FTP sever
Password
User password
Storage Path
Storage Path where video and image will be uploaded to the FTP server.
Four FTP storage path types are available, including Root Directory, Parent
Directory, Child Directory and Customize.
Parent Directory
Choose IP Address/ Device Name/ Date as the folder name of Parent Directory, or
customize the folder name.
Child Directory
Choose IP Address/ Device Name/ Date as the folder name of Child Directory, or
customize the folder name.
Multilevel Folder
Name
If the storage path is more than two levels, enter Multilevel FTP storage path here
manually.
Alarm Action File
Name
Choose the default(YYYY-MM-DD) or customize the alarm action file name.
Video File Name
If you choose to customize video file name, YYYY-MM-DD/ MM-DD-YYYY/
DD-MM-YYYY/ Add prefix/ Customize are available.
Image File Name
If you choose to customize image file name, YYYY-MM-DD/ MM-DD-YYYY/
DD-MM-YYYY/ Add prefix/ Customize are available.
Timing Snapshot File
Name
Default(YYYY-MM-DD) /MM-DD-YYYY/ DD-MM-YYYY/ Add prefix/ Overwrite with
the base file name/ Customize are available.
Note:
1) Parent Directory will be under Root Directory, and Child Directory will be under Parent
Directory.
2) You can refer to the following file name tip to customize the file name.
VLAN
A virtual LAN (VLAN) is any broadcast domain that is partitioned and isolated in a computer
network at the data link layer (OSI layer 2). LAN is an abbreviation of local area network. VLANs
allow network administrators to group hosts together even if the hosts are not on the same
network switch. This can greatly simplify network design and deployment, because VLAN
membership can be configured through software. Without VLANs, grouping hosts according to
their resource needs necessitates the labour of relocating nodes or rewiring data links.
