28
01
Discrete
02
Input16_AB
03
Input16_BA
04
Input32_ABCD
05
Input32_BADC
06
Input32_CDAB
07
Input32_DCBA
08
Input32_AB
09
Input32_CD
0a
Input_float_ABCD
0b
Input_float_BADC
0c
Input_float_CDAB
0d
Input_float_DCBA
0e
Hold16_AB
0f
Hold16_BA
10
Hold32_ABCD
11
Hold32_BADC
12
Hold32_CDAB
13
Hold32_DCBA
14
Hold32_AB
15
Hold32_CD
16
Hold_float_ABCD
17
Hold_float_BADC
18
Hold_float_CDAB
19
Hold_float_DCBA
Delete Modbus Channel
ef
00+Channel ID (1B)
Mobus Channel Name
ef
02+Channel ID (1B) + Name Length
(1B) + Name (Mutable)
Note: Channel ID in downlink commands is different from uplinks:
Channel ID
Description
01
RS485 (Modbus Master) Channel 1
02
RS485 (Modbus Master) Channel 2
03
RS485 (Modbus Master) Channel 3
...
...
20
RS485 (Modbus Master) Channel 32
Examples:
1. Set reporting interval as 20 minutes.
ff 03 b0 04
Channel
Type
Value
ff
03
b0 04 => 04 b0 = 1200 s = 20 mins
