Millenium Mechatronics MI104 - Specifications

MI104 Weighing Indicator User Manual
- 3 -
1. SPECIFICATIONS
Model
MI104
Resolution
1/30,000
Indicator housing
ABS Plastic
Stabilisation Time
1 Seconds typical
Operating Temperature
0°C ~ +40°C / 32°F - 104°F
Power supply (external)
AC Adaptor (12V/500mA) /
Ni-MH battery (1.2V/2000mAh x 6)
Calibration
External
Display
6 digits 22mm LCD display, attached backlight
Interface
RS-232 Output Optional
Zero range
0mV~5mV
Signal input range
0~15mV
ADC
Sigma delta
ADC update
Max 60 times /second
Load cell Excitation voltage
Max 5V/150mA
