Miller 22A - Specifications; Serial Number and Rating Label Location; Unit Specifications; Environmental Specifications

OM-193472 Page 12
SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the rear panel. Use rating label to determine input power requirements and/or
rated output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Unit Specifications
Type of Input
Power
Welding Power
Source Type
Wire Feed
Speed Range
Wire
Diameter
Range
Welding
Circuit Rating
Overall
Dimensions
Weight
24 Volts AC Single
Phase
7 Amperes 50/60
Hz
Constant Voltage
(CV) DC With
14-Pin And
Contactor Control
75 to 750 ipm
(1.9 To 19 mpm)
.023 To 5/64 in.
(0.6 To 2 mm)
Max Spool
Capacity:
18 in. (457 mm)
Max Spool Weight:
60 lb (27 kg)
100 Volts,
500 Amperes,
100%
Duty Cycle
Length: 23-1/2 in.
(597 mm)
Width: 10-3/4 in.
(273 mm)
Height: 11 in.
(279 mm)
35 lb (15.9 kg)
4-3. Environmental Specifications
A. IP Rating
IP Rating
IP21S
This equipment is designed for indoor use and is not intended to be used or stored outside.
IP21S 2014−06
B. Temperature Specifications
Operating Temperature Range Storage Temperature Range
14 to 104°F (−10 to 40°C) −4 to 131°F (−20 to 55°C)
Temp_2016- 07
C. Information On Electromagnetic Compatibility (EMC)
! This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low−
voltage supply system. There can be potential difficulties in ensuring electromagnetic compatibility in those locations, due to con-
ducted as well as radiated disturbances.
ce-emc 3 2014-07
Notes
