Miller DYNASTY 200 DX User Manual

OM-2240 Page 25
5-5. Voltmeter
1 Volt Meter
Displays output or open circuit volt-
age. If output is off, the voltmeter will
display a series of three dashes
(-−−). Open circuit voltage is dis-
played if power is on and output is
available.
1
5-6. Polarity Control (Dynastyt Models Only)
1 Polarity Control
Press switch pad until desired LED
is illuminated.
DC - Machine is set to DCEN (direct
current electrode negative) for TIG
welding, and to DCEP (direct cur-
rent electrode positive) for Stick
welding.
AC - Use AC (alternating current)
for TIG and Stick welding.
1

Miller DYNASTY 200 DX Specifications

General

Welding Amperage Range	1-200 A
Output Current Range	1-200 A
Pulse Frequency	0.5 - 500 Hz
AC Frequency	20-250 Hz
Processes	TIG (GTAW), Stick (SMAW)
Output Power	200 A at 26 V, 40% duty cycle
Input Power	120 V, 208 V, 220/230/240 V, 460 V, 575 V, 1- or 3-Phase
