T94, T94i, and
T94i XL
Series
Auto-Darkening Helmets
OM-255503E 2021-05
T94 T94i T94i XL
OWNER’S MANUAL

Table of Contents

Other manuals for Miller T94 Series

Preview: Manual
Manual32 pages

Questions and Answers

  • J
    Jeffrey SmithAug 18, 2025
    What to do if my Miller Motorcycle Accessories auto-lens is not switching and stays light?
    • R
      Richard DayAug 18, 2025
      If your Miller Motorcycle Accessories auto-lens stays light and won't darken during welding, stop welding immediately. Press the Mode (On/Off) button. If the power is On, check the sensitivity and adjust it accordingly. Clean the lens cover and sensors to remove any obstructions. Ensure the sensors face the arc; angles of 45 degrees or more may prevent the arc light from reaching the sensors.
  • H
    Heather WallAug 20, 2025
    What to do if my Miller T94 Motorcycle Accessories auto-lens is not turning on?
    • D
      David ClarkAug 20, 2025
      If the auto-lens settings on your Miller Motorcycle Accessories do not appear when you press the Mode button, check the battery. Make sure it's in good condition and installed correctly. Inspect the battery surfaces and contacts, and clean them if needed. Also, ensure the battery has proper contact; gently adjust the contact points if necessary. This is especially important if the helmet has been dropped.
  • T
    Toni AndersonAug 23, 2025
    What to do if my Miller T94 Motorcycle Accessories auto-lens has sections that are not going dark?
    • E
      Elizabeth GreerAug 23, 2025
      If sections of your Miller Motorcycle Accessories auto-lens are not going dark, and you see distinct lines separating light and dark areas, stop welding immediately. This may be due to a cracked auto-lens, possibly from dropping the helmet, or weld spatter. The lens may need replacement, but note that most cracked lenses are not covered under warranty.
  • A
    Alicia BakerAug 26, 2025
    What to do if Miller Welding Accessories auto-lens is switching or flickering?
    • L
      Larry KingAug 26, 2025
      If your Miller Welding Accessories auto-lens is flickering during welding or cutting, review the sensitivity setting recommendations and increase the sensitivity if possible. Make sure the arc sensors aren't blocked from the arc light. Also, check the lens cover for dirt and spatter. Increasing the lens delay to 0.1 - 0.3 seconds might also help reduce the switching.
  • D
    Dr. Troy Scott MDAug 27, 2025
    How to fix Miller Welding Accessories auto lens not turning on?
    • M
      Michael CarrAug 27, 2025
      If your Miller Welding Accessories auto-lens isn't turning on, check the batteries to ensure they're in good condition and installed correctly. Clean the battery surfaces and contacts if necessary. Also, check the battery for proper contact and gently adjust the contact points, especially if the helmet has been dropped.
  • J
    Jacqueline BrownAug 30, 2025
    Why Miller Welding Accessories auto-lens has inconsistent shading?
    • A
      Albert GarzaAug 30, 2025
      The inconsistent or lighter shading you're seeing on the edges and corners of your Miller Welding Accessories auto-lens is referred to as an angle of view effect. Auto-darkening lenses have an optimal viewing angle of 90° to the lens surface. When the viewing angle varies in the dark state, welders might notice lighter areas at the edges and corners, which is normal and not a safety hazard.
  • S
    simsashleySep 1, 2025
    What to do if sections of Miller Welding Accessories auto-lens are not going dark?
    • O
      Oscar RiddleSep 2, 2025
      If sections of your Miller Welding Accessories auto-lens aren't darkening and distinct lines separate the light and dark areas, stop welding or cutting immediately. The auto-lens may be cracked, possibly from dropping the helmet or weld spatter. The lens may need replacing, but most cracked lenses aren't covered by warranty.
  • D
    Dawn AyersSep 4, 2025
    Why is my Miller T94 Motorcycle Accessories auto-lens switching or flickering?
    • C
      Cory PageSep 4, 2025
      If your Miller Motorcycle Accessories auto-lens darkens and lightens while welding, review the sensitivity setting and increase it if possible. Make sure that nothing is blocking the arc sensors from direct access to the arc light. Inspect the lens cover for dirt and spatter. Increasing the Lens Delay to 0.1 – 0.3 seconds might also help reduce the switching.
  • C
    Cheryl BerrySep 7, 2025
    What to do if my Miller Motorcycle Accessories auto-lens stays dark after welding?
    • C
      Crystal TorresSep 7, 2025
      If your Miller Motorcycle Accessories auto-lens stays dark after the weld arc is extinguished, or stays dark when no arc is present, fine-tune the sensitivity setting in small increments. In very bright conditions, try reducing the surrounding light levels.
  • R
    Rebecca HowellSep 9, 2025
    Why is my Miller T94 auto-lens shading inconsistent?
    • T
      tina32Sep 9, 2025
      Inconsistent or lighter shading on the edges and corners of your Miller Motorcycle Accessories auto-lens, also known as an angle of view effect, is normal. Auto-darkening lenses have an optimum viewing angle of 90 degrees to the lens surface. When the viewing angle varies in the dark state, slightly lighter areas may appear at the edges and corners. This is not a safety hazard and may be more noticeable when using magnifying lenses.

Summary

Safety Precautions

Symbol Usage

Explains the meaning of danger, warning, and notice symbols used in the manual for hazard identification.

Arc Welding Hazards

Details hazards associated with arc welding, including arc rays, noise, fumes, and gases.

California Proposition 65 Warnings

Provides a warning regarding cancer and reproductive harm, referencing the official California government website.

Lens Shade Selection Guide

Table providing recommended lens shade numbers based on welding process, electrode size, and arc current.

Principal Safety Standards

Lists key industry standards (ANSI, CSA, SAI Global) related to welding safety and protection.

Specifications

Viewing Field

Details the dimensions of the viewing area for the T94/T94i and T94i XL helmets.

Reaction Time

Specifies the auto-darkening lens reaction time for the T94, T94i, and T94i XL models.

Available Shades

Lists the range of shade numbers available in Weld, Cut, Grind, and X-Modes for different helmet models.

Sensitivity Control

Describes the adjustable sensitivity feature for varying light levels and welding arc conditions.

Delay Control

Details the delay setting range for the lens to switch from dark to light state after welding.

Power Supply

Identifies the type of battery used (Panasonic CR2450 Lithium) and quantity required for each helmet model.

Operating Temperature

Specifies the recommended operating temperature range for the auto-darkening helmet.

Storage Temperature

Defines the acceptable temperature range for storing the welding helmet.

Total Weight

Provides the total weight specifications for the T94, T94i, and T94i XL helmet models.

Standards Compliance

Confirms compliance with industry safety standards such as ANSI Z87.1+ and CSA Z94.3.

Warranty Information

Outlines the warranty period for the auto-darkening lens helmet.

Operating Instructions

Helmet Configurations

Describes the differences between the T94 and T94i/T94i XL helmet models, focusing on lens type and features.

Helmet Controls Overview

Identifies and explains the function of various buttons and indicators on the helmet's digital control panel.

Mode Button and Indicator Light Functions

Explains the operation of the Mode button and the functions of the Grind/Low Battery/Memory indicator light.

Mode Control Settings Explained

Details the different operating modes (Weld, Cut, Grind, X-Mode) and their specific settings and functionalities.

Variable Shade Control

Guides users on how to adjust the lens shade level using the '+' and '-' buttons for optimal welding visibility.

Lens Delay Control

Explains how to adjust the delay time for the lens to switch from dark to clear state after welding.

Sensitivity Control

Details how to adjust the lens sensitivity to react to different light levels and welding arc conditions.

Typical Lens Adjustment Procedure

Provides a step-by-step guide for adjusting the helmet's lens settings (mode, shade, delay, sensitivity).

Arc Time and Arc Count

Explains the functions for recording the total arc time and the number of times the lens darkens.

Memory Control

Details how to save and recall two preset modes with customized shade, delay, and sensitivity settings.

Adjusting Headgear

Headgear Adjustment Points

Describes the four headgear adjustments: top, tightness, angle, and distance for optimal fit and stability.

Replacing Lens Covers

Replacing Grind Shield

Instructions for removing and installing the HDV grinding shield on T94i and T94i XL helmets.

Replacing Cover Lenses

Step-by-step guide for replacing the outside and inside lens covers for proper protection.

Replacing the Battery

Battery Replacement Procedure

Details the process of removing the lens assembly and replacing the battery, including correct polarity.

Installing Optional Magnifying Lens

Magnifying Lens Installation

Instructions for installing an optional magnifying lens using an adapter frame, including orientation for fog prevention.

Maintenance and Storage

Cleaning and Care

Guidelines on cleaning the helmet and its components using mild soap and water, and avoiding harsh chemicals.

Storage Recommendations

Advice on storing the helmet in a clean, dry, cool place and removing batteries for long-term storage.

Troubleshooting

Troubleshooting Common Issues

Provides solutions for common problems such as the auto lens not darkening, staying dark, or flickering.

Parts List

Limited Warranty

Warranty Terms and Conditions

Details the warranty period, coverage, and requirements for the Miller auto-darkening lens helmet.

Miller T94 Series Specifications

General IconGeneral
BrandMiller
ModelT94 Series
CategoryMotorcycle Accessories
LanguageEnglish
