OM-181 712 Page 11
SECTION 3 DEFINITIONS
3-1. Symbols And Definitions
. Some symbols are found only on CE products.
Output Alternating Current
A
Amperes
V
Volts
Single Phase
X
Duty Cycle
Hz
Hertz
IP
Degree Of Protec-
tion
Read Instructions Percent
U
1
Primary Voltage
U
2
Conventional Load
Voltage
Line Connection
I
1
Primary Current
I
2
Rated Welding
Current
Notes
