Milli-Q IX 7003 - Installation Component

Introduction
2
Installation components
Milli-Q
®
IX 7003/7005/7010/7015 consists of at least 3 different components: water system
(Milli-Q
®
IX 7003 on the photographs below), tank, and E-POD
®
unit.
1
Front view of a Milli-Q
®
IX 7003 water
system
6
E-POD
®
unit (Point of Dispense of pure
water) with screen interface
2 Front cover 7
POD dispenser (equipped with a Milli-
pak
®
nal lter on the photograph)
3
Front view of a Milli-Q
®
IX 7003 water
purication unit, with the front cover
removed
8 Dispensing wheel
4 Accessories holder 9 POD base
5
Rear view of a Milli-Q
®
IX 7003 system
with its hydraulic and electrical connec-
tions
10
Storage tank (50L capacity on the pho-
tograph)
Note: The system can either have one IPAK Gard® cartridge (Milli-Q® IX 7003/7005 system)
or two (Milli-Q® IX 7010/7015 system). On the photograph, the accessories holder is used to
store the sanitization port tool and the RO cleaning tablets bottle (ROProtect C - SDS available
on www.merckmillipore.com or www.emdmillipore.com).
8
9
1
5 6
7
10
2 3
4
