INTERCONNECTION
Load cell or LVDT, speed sensor, analog mA output, auto zero and low voltage contact wiring may be run in a
common conduit. However, these may not be run in the same conduit as high voltage contact or power wiring.
SYSTEM DIAGRAM
Compu-M
load sensor
(e.g. beltscale or flowmeter)
speed sensor
(optional)
customer device
customer alarm
or control device
customer remote
totalizer
relay output
totalizer output
mA output
