Milltronics COMPU-M User Manual

SPECIFICATIONS
COMPU-M
Power : » standard : » 100/115/200/230 V ac ± 10%, 50/60 Hz, 15 VA
» optional : » 12 ± 2 V dc, 15 W
» 24 ± 4 V dc, 15 W
Environmental : » location : » indoor
» altitude : » 2000 m max
» ambient temperature : » – 20 to 50 °C (– 5 to 122 °F)
» relative humidity : » 80 % for temperatures up to 50 °C
» installation category : » II
» pollution degree : » 2
Inputs : » load cell : » 0 - 45 mV dc per load cell, 2 cells maximum
» LVDT : » 0 - 0.75 V rms, 2.9 kHz
» speed sensor : » 5 - 15 V dc pulses, 2 Hz to 10 kHz (for belt scales only)
Outputs : » analog : » 0.1% resolution
» 0 - 20 or 4 - 20 mA, non-isolated
» 750 Ω maximum load
» speed sensor excitation : » 12 V dc, 50 mA maximum
» totalizer, remote : » contact closure 32-288 ms duration
» 1 form "C" relay contact rated 2 A at 250 V ac,
50 VA maximum resistive
» 15 closures per second maximum
» alarm relay : » 1 S.P.D.T. contact rated at 5 A at 250 V ac non-inductive
» load cell excitation : » 10 V dc nominal, 100 mA maximum
» LVDT excitation : » 2.5 V ac rms, 2.9 kHz
Displays : » liquid crystal : » 8 digits, 13 mm (0.5") high with backlight
» LED : » 4 display mode indicators
Accuracy : » ± 0.1% of span
PL-516 7
