CHAPTER 3 – SITE PREPARATION
25
Air Supply System (if equipped)
Depending on options (air collet, pneumatic gear shift mechanism), some Milltronics
lathes require a constant supply of quality air pressure in order to perform optimally. 90-
110 PSI at 10 CFM is required.
Adjustments
• Set the main air regulator to 90 PSI.
• Set the drop rate on the lubricator to approximately 1 drop per every 1-2 gear
changes
Main air pressure
gauge. Adjust
using knob “A”.
to 90 PSI
Air pressure
switch adjusted
to trip at 75 PSI.
Weekly fill with
Marvel No.085,
Mobil Velocite No.
10 or equivalent.
Water trap is self-
draining. No need
to drain manually.
