ML30-ML45 Specifications
Effective March 1, 2006
Machine Model ML35/80 ML40/80
Control Type Centurion 7T Centurion 7T
Functions
Dual Handwheel, Handwheel Teach, Conversational
G/M Code, Manual or Automatic Operation of Spindle
RPM and Coolant
CAPACITY
Swing Over Bed
36.2" 920 mm 39.7" 1010 mm
Swing Over Gap
Contact factory for limitations
45" 1150 mm (dia.)
14.6" 372 mm Gap
50" 1280 mm (dia.)
14.6" 372 mm Gap
Swing Over Cross Slide
21.6" 550 mm 26.6" 676 mm
Cross Slide Tool Holder Mounting Surface T-Slots T-Slots
Cross Slide "T" Slots 18 mm 18 mm
Travel (X Axis) Cross Slide
19" 480 mm 21" 550 mm
Travel (Z Axis) with tailstock 80" Bed 87" 2210 mm 87" 2210 mm
Travel (Z Axis) with tailstock 120" Bed 120" 3000 mm 120" 3000 mm
Travel (Z Axis) with tailstock 160" Bed 160" 4000 mm 160" 4000 mm
Travel (Z Axis) with tailstock 200" Bed 200" 5000 mm 200" 5000 mm
Travel (Z Axis) with tailstock 240" Bed 240" 6000 mm 240" 6000 mm
Z Cutting Length with Turret
Consult factory Consult factory
Center Distance 80" Bed
86" 2200 mm 80" 2000 mm
Center Distance 120" Bed 126" 3200 mm 120" 3000 mm
Center Distance 160" Bed 165" 4200 mm 160" 4000 mm
Center Distance 200" Bed 205" 5200 mm 200" 5000 mm
Center Distance 240" Bed 244" 6200 mm 240" 6000 mm
Bed Width
22" 560 mm 22" 560 mm
Machine Weight 80" Bed
Add 2200 lbs 1000 kg for each 40" of extended bed
length
16,500 lb 7500 kg 29,500 lb 13,350 kg
Ball Screw Size – 80" Bed Length
X 40 mm Z 63 mm X 40 mm Z 63 mm
Ball Screw Size – 160" - 240" Bed Length
X 40 mm Z 80 mm X 40 mm Z 80 mm
Ball Screw Grade C5 Precision Ground C5 Precision Ground
Ball Screw Pitch X axis / Z axis 5 mm / 12 mm 5 mm / 10 mm
Maximum Weight of Part With Chuck and Supported
From Center
6600 lb 3000 kg 8800 lb 4000 kg
SPINDLE
Spindle Drive System
Two Speed Auto Shift Geared Transmission with
Closed Loop Digital Vector Drive System
Standard Horsepower 1 minute / 30 minutes
35/25 HP 26/18 kw 35/25 HP 26/18 kw
Optional Horsepower
1 minute / 30 minutes (Performance Package C)
44/30 HP
33/22 kw
44/30 HP
33/22 kw
Spindle Programmable Resolution – with Orient Option 0.01 ° 0.01 °
Spindle Orient Positioning Accuracy – with Orient Option ± 0.16 ° ± 0.16 °
Spindle Speed 4" Spindle Bore
*
Important notice: RPM may be limited due to chuck size and
workpiece
10 - 1480 10 - 1480
Spindle Range 1 – 4" Spindle Bore 10 - 375 10 - 375
Spindle Range 2 – 4" Spindle Bore 10 - 1480 10 - 1480
Spindle Speed 6" Spindle Bore *See note above 10 - 1480 10 - 1480
Spindle Range 1 – 6" Spindle Bore 10 - 375 10 - 375
Spindle Range 2 – 6" Spindle Bore 10 - 1480 10 - 1480
Spindle Speed 10" Spindle Bore *See note above 10 - 750 10 - 750
Spindle Range 1 – 10" Spindle Bore
10 - 375 10 - 375
