Milltronics ML Series User Manual

Machine Model ML35/80 ML40/80
Spindle Range 2 – 10" Spindle Bore
10 - 750 10 - 750
Spindle Speed 14" Spindle Bore *See note above 10 - 500 10 - 500
Spindle Range 1 – 14" Spindle Bore 10 - 375 10 - 375
Spindle Range 2 – 14" Spindle Bore 10 - 500 10 - 500
Standard Spindle Bore
4.17" 106 mm 4.17" 106 mm
Optional Spindle Bore 6.02" 153 mm 6.02" 153 mm
Optional Spindle Bore 10" 254 mm 10" 254 mm
Optional Spindle Bore
14" 355 mm 14" 355 mm
Spindle Nose Type – Standard Bore 4" 106 mm
A2-11 A2-11
Spindle Nose Type – Optional Bore 6" 153 mm
A2-11 A2-11
Spindle Nose Type – Optional Bore 10" 254 mm A2-15 A2-15
Spindle Nose Type – Optional Bore 14" 355 mm
A2-20 A2-20
Tailstock Quill Travel 8" 200 mm 9" 230 mm
Tailstock Quill Diameter 4.92" 125 mm 4.92" 125 mm
Tailstock Quill Taper MT6 MT6
TOOLING ACCESSORIES – Contact factory for live tooling Specifications
Super Dorian Tool Post Option
SD60EA 1.5" 40 mm SD60EA 1.5" 40 mm
8 Station Auto Turret Option – 1" Specify if metric is
desired
1" x 5" 25 x 125 mm 1" x 5" 25 x 125 mm
12 Station Auto Turret Option – 1" Specify if metric is
desired
1" x 5.5" 25 x 140 mm 1" x 5.5" 25 x 140 mm
12 Station Auto Turret Option – 1 ¼" Specify if Metric is
desired
1.25" x 6" 32 x 150 mm 1.25" x 6" 32 x 150 mm
8 Station Auto Turret Option – 1 ½" Specify if metric is
desired
1.5" x 6" 38 x 150 mm 1.5" x 6" 38 x 150 mm
Turret Boring Bar Capacity – 1" Turret
1.5" 40 mm 1.5" 40 mm
Turret Boring Bar Capacity – 1 ¼" & 1 ½" Turret
2" 50 mm 2" 50 mm
Turret Boring Bar Sleeve – 1" Turret
1.5" dia x 3"
40 mm x 76 mm
1.5" dia x 3"
40 mm x 76 mm
Turret Boring Bar Sleeve – 1 ½" & 1 ¼" Turret
2" x 3.5" 50x88mm 2" x 3.5" 50x88mm
Steady Rest Roller Type- Convenience Package B 1.9 - 11.8" 50 - 300 mm 1.9 - 11.8" 50 - 300 mm
Optional Steady Rest Roller Type
9.8 - 17.7" 250 - 450 mm 9.8 – 19.6" 250 - 500 mm
Follow Rest Brass Tip - Convenience Package B 1.1 - 7.8" 30 - 200 mm 1.1 - 7.8" 30 - 200 mm
PERFORMANCE
Servo Type AC AC
Rapid Traverse XZ 500 ipm 12.7 mpm 500 ipm 12.7 mpm
Maximum Feedrate
100 ipm 2540 mmpm 100 ipm 2540 mmpm
Position Accuracy
See note
± .00025" 0.0063 mm ± .00025" 0.0063 mm
Repeatability
See note
0.00039" 0.010 mm 0.00039" 0.010 mm
Resolution 0.00004" 0.001 mm 0.00004" 0.001 mm
Thrust, Machine Duty Rating
X: 6700 lb 3000 kg
Z: 6700 lb 3000 kg
X: 6700 lb 3000 kg
Z: 6700 lb 3000 kg
MISCELLANEOUS ML35/80 ML40/80
Flood Coolant Capacity – 80" Bed 90 gal 340 L 90 gal 340 L
Flood Coolant Capacity – 120" Bed 85 gal 320 L 85 gal 320 L
Flood Coolant Capacity – 160" Bed 110 gal 420 L 110 gal 420 L
Flood Coolant Capacity – 200" Bed 140 gal 530 L 140 gal 530 L
Flood Coolant Capacity – 240" Bed 150 gal 564 L 150 gal 564 L
Way Surface
Hardened and Ground Square Box Turcite Ways
Power 208-240 VAC, 50-60hz, 3Ø 100 amps 34 KVA 100 amps 34 KVA
Power 208-240 VAC, Single Phase Not Available Not Available
400-440 VAC Requires Transformer 34 KVA 34 KVA
65
