Follow Rest Brass Tip - Convenience
Package B
.4 - 4"
10 - 100 mm
.4 - 4"
10 - 100 mm
.75 - 7.8"
20 - 200 mm
.75 - 7.8"
20 - 200 mm
Optional Steady Rest Roller Type N/A N/A
5.9 - 11.8"
150 - 300 mm
5.9 - 11.8"
150 - 300 mm
PERFORMANCE ML16 ML18 ML22 ML26
Servo Type AC AC AC AC
Rapid Traverse
XZ: 500 ipm
12.7 mpm
XZ: 500 ipm
12.7 mpm
XZ: 500 ipm
12.7 mpm
XZ: 500 ipm
12.7 mpm
Maximum Feedrate
100 ipm
2540 mmpm
100 ipm
2540 mmpm
100 ipm
2540 mmpm
100 ipm
2540 mmpm
Position Accuracy
See note
±.00025"
.0063 mm
±.00025"
.0063 mm
±.00025"
.0063 mm
±.00025"
.0063 mm
Repeatability
See note
.0002" .005 mm .0002" .005 mm .0002" .005 mm .0002" .005 mm
Resolution .00004" .001 mm .00004" .001 mm .00004" .001 mm .00004" .001 mm
Thrust, Machine Duty Rating
X: 1500 lb 680 kg
Z: 1500 lb 680 kg
X: 1500 lb 680 kg
Z: 1500 lb 680 kg
X: 2300 lb 1040 kg
Z: 2300 lb 1040
kg
X: 4000 lb 1815 kg
Z: 4000 lb 1815 kg
MISCELLANEOUS
Optional Barfeeder - Bar Diameter
.2 - 2.55"
5 - 65 mm
.2 - 2.55"
5 - 65 mm
.2 - 2.55"
5 - 65 mm
.2 - 2.55"
5 - 65 mm
Optional Barfeeder - Maximum Bar Length 50" 1250 mm 50" 1250 mm 50" 1250 mm 50" 1250 mm
Optional Barfeeder - Loading Capacity
10 Bars x 2.55" 65
mm
10 Bars x 2.55"
65 mm
10 Bars x 2.55"
65 mm
10 Bars x 2.55"
65 mm
Flood Pump ¾ HP ¾ HP ¾ HP ¾ HP
Flood Coolant Capacity 20 gal. 75 L 26 gal. 100 L 50 gal. 190 L 50 gal. 190 L
Power 208-240 VAC, 50-60hz, 3Ø 50 amps 11 KVA 50 amps 11 KVA 75 amps 20 KVA 75 amps 20 KVA
Power 208-240 VAC, Single Phase Optional Optional Optional Optional
400-440 VAC Transformer Req. 11 KVA Req. 11 KVA Req. 20 KVA
Req. 20 KVA
Floor Space Requirement 40" Bed Machine
83 " x 120"
2110 x 3050 mm
N/A N/A
94" x 120"
2390 x 3050 mm
Floor Space Requirement 60" Bed Machine N/A
71" x 138"
1800 x 3510mm
83" x 137"
2100 x 3480 mm
N/A
Floor Space Requirement 80" Bed Machine N/A N/A N/A
94" x 158"
2390 x 4000 mm
Floor Space Requirement 120" Bed Machine N/A N/A
N/A
118" x 205"
3000 x 5200 mm
Floor Space Requirement 160" Bed Machine N/A N/A
N/A
90 x 244"
2390 x 6190 mm
Warranty
Parts: One year or 2100 hours, whichever occurs first on all normal
failures.
Service: One year or 2100 hours (whichever occurs first) from dealer or
available from factory during second six months if air ticket supplied.
Extended Parts Warranty for
Second Year
Parts warranty for normal failures for up to two years or 4200 hours,
whichever occurs first.
Measurements performed with Renishaw laser and ballbar systems. Measurements are linear over entire travel,
and temperature changes and table loads may affect tolerances. Tolerances are guaranteed over 10" sq. area.
Centurion features covered under separate literature. For machine duty rating, see "Truth in Specifications" on
www.milltronics.net.
Milltronics reserves the right to change specifications at any time without incurring obligation.
