CHAPTER 7 – 7200 CNC OPERATION
8) SPINDLE CW/STOP/CCW (Use along with #10 ENABLE on lathe controls)
o Spindle CW button – starts spindle in clockwise direction provided there is
a programmed spindle rpm.
o Spindle CCW button – starts spindle in counter-clockwise direction
provided there is a programmed spindle rpm.
o Spindle STOP button – stops spindle rotation.
9) EMERGENCY STOP button – Disables machine motion, control enable, and axis
waylube oiler. Emergency stop buttons lock down when pressed and must be
rotated to release.
10) ENABLE button – When pressed and released it enables axis and spindle
drives. All Emergency stop and limit switches must be released for drives to
enable.
11) Alphanumeric keypads – used to enter characters in MDI mode or program
mode.
12) Function keypad – used to select machine functions that are shown along the
bottom of the operator’s panel display.
53
