Milltronics ML Series User Manual

60
T
T
T
L
L
L
1
1
1
4
4
4
/
/
/
4
4
4
0
0
0
T
T
T
L
L
L
1
1
1
5
5
5
/
/
/
4
4
4
0
0
0
Rapid Traverse 300 ipm 7.6 mpm 300 ipm 7.6 mpm
Feedrate Range
.1-100 ipm
2.5 - 2540 mmpm
.1-100 ipm
2.5 - 2540 mmpm
Position Accuracy
See note
±.0004" .010 mm ±.0004" .010 mm
Repeatability
See note
.0004" .001 mm .0003" .0076 mm
Resolution .0001" .001 mm .0001" .001 mm
Thrust, Machine Duty Rating
X: 800 lbs. 360 kg
Z: 1600 lbs. 725 kg
X: 1000 lbs 450 kg
Z: 2000 lbs 900 kg
CENTURION 7 CNC
Control, PC Based Standard Standard
LCD Color Display Standard Standard
Keys & Buttons, Tactile Standard Standard
Upgrade to Discrete Key Front Panel Optional Optional
Conversational & G/M Code with Full Graphics Standard Standard
Turning, Facing, Grooving, Tapping and Boring Cycles, and
User-definable Macros with Trig Help
Package A Package A
Constant Surface (RPM changes with radius) and Feed/Rev.
(IPR) with Threading Cycles
Package A Package A
Pattern Repeat, Chamfering, Radius Prog. Assist with Handwheel
Teach Mode
Package A Package A
Dual Handwheel Station for Selecting Teach, Manual or Automatic
Operation
Package B Package B
2 Mb Parts Storage Memory Standard Standard
Additional 8 Mb Parts Storage Memory Package A Package A
6 Mb Virtual Disk / DNC buffer Standard Standard
8 Mb Program Execution Memory Package A Package A
Additional 16 Mb Program Execution Memory Package C Package C
Networking Package C Package C
256 Mb Memory Capacity Package C Package C
3 ½" Floppy Drive Package A Package A
MISCELLANEOUS
Automatic Home Sequence, Chuck Guards, Safety Switch Standard Standard
5C Royal Collet Closer with Foot Switch Optional Optional
Work Lamp Package B Package B
Full Enclosure with Sliding Doors and Safety Switch Standard Standard
Auto Metered Lubrication with Low Lube Fault Standard Standard
1/8 Horsepower Flood Pump Option Package B Package B
Flood Coolant Capacity 25 gal. 90 L 25 gal. 90 L
Way Surface Hardened/Ground Hardened/Ground
Power Requirements 208-240 VAC, 50 – 60 hz, 3Ø 30 amps 11 kVA 30 amps 11 kVA
Power 208-240 VAC, Single Phase Optional Optional
Power 380-480 VAC, 50 – 60 hz, 3Ø Req Transformer Req Transformer
Warranty
Parts: 2 Years (or 4200 hours, whichever occurs first) on all normal failures.
Service: 1 Year (or 2100 hours, whichever occurs first) from dealer or
available from factory for second 6 months if air ticket supplied.
Floor Space Requirement 60" x 104" 1524 x 2640 mm 74" x 109" 1875 x 2760 mm
Notes: Measurements performed with Renishaw laser. Measurements are linear over entire travel, and
temperature changes and loading may affect tolerances. Centurion features covered under separate
literature. Additional Centurion 7 features and additional options covered under separate literature.
Milltronics reserves the right to change specifications at any time without incurring obligation.
