SELECTING TEMPERATURE SOURCE
CURRENT OUTPUT
to customer’s equipment
maximum loading 350 Ω
mA Output - GROUNDED
(additional to basic wiring)
Note : TB1-2 is internally
connected to electrical
ground TB1-28.
mA Output - FLOATING
(additional to basic wiring)
mA output wiring into floating input ONLY.
750 Ω max. Do Not Ground!
board ‘B’
Integral Sensor (transducer)
TS-3 or Program
PL-443 3 – 4
To Next Page
