General Relays Pump Control Vol. & Disp.
Conversion
OCM Totalizer Custom Filter
P-1 units P-8 1 function P-23 submers. P-34 tank P-40 primary P-51 OCM sim. P-60 full P-68 fill damp
P-2 mode P-9 1 on P-24 1 hrs. P-35 dim. A P-41 time P-52 factor P-61 empty P-69 empty damp
P-3 empty dist. P-10 1 off P-25 2 hrs. P-36 dim. L P-42 expon. P-53 decimal P-62 offset P-70 rate disp.
P-4 span P-11 2 function P-26 3 hrs. P-37 convert P-43 flume dim. P-54 low tot. P-63 vel. 20 °C P-71 rate avg.
P-5 near blank P-12 2 on P-27 4 hrs. P-38 disp. offset P-44 spare P-55 high tot. P-64 vel. P-65 P-72 fuzz filter
P-6 mA out P-13 2 off P-28 5 hrs. P-39 disp. opt’n P-45 max. head P-56 remote tot. P-65 temp. P-73 agitator
P-7 decimal P-14 3 function P-29 run-on P-46 max. flow P-57 flow samp. P-66 max. temp P-74 f-s mode
P-15 3 on P-30 run-on P-47 auto zero P-58 flow samp. P-67 min. temp P-75 f-s timer
P-16 3 off P-31 spare P-48 cutoff P-59 time samp.
P-17 4 function P-32 DLD mA out P-49 decimal
P-18 4 on P-33 totaling P-50 mA out
P-19 4 off
P-20 5 function
P-21 5 on
P-22 5 off
PUMP CONTROL
APPLICATION PARAMETERS
P-# required parameters
P-# optional parameters
P-# parameters not required
