ANALOG OUTPUT
The MultiRanger Plus can be programmed to provide analog output (P-6) of 0 or
4 - 20 mA, proportional or inverse span.
The 4 and 20 mA levels can be trimmed slightly via P-97 and P-98 respectively
to compensate for any offset between the MultiRanger Plus and the
customer’s equipment.
The analog output feature can be turned OFF by setting P-6=0. The output and
alternate displays(5 &P-92) will immediately drop to 0 mA after a new measurement
is processed. The output will remain disabled during simulation (P-76,77, & 78)
However, the test routine of P- 92 and the trim parameters will remain active.
If P-60 = 0, then the analog output will return to its programmed output after a new
measurement is processed.
If the analog output must be isolated, the optional LIs-1 mA isolator must be mounted
on the motherboard and wired. When using the isolator, the load adjust can be done
via P-97 and 98 rather than via the load adjust potentiometer.
The analog output responds in the following manner :
MODES
P2 = 1
LEVEL
P2 = 2
SPACE
P2 = 3
DLD
P2 =1
VOLUME
P2 = 4
PUMP
TOTAL
P2 = 5
OCM
A
N
A
L
O
G
O
U
T
P
U
responds
to
material
level
material
distance
differential
(if P-32 = 1)
level on
xdcr 1
(if P-32 = 2)
volume level
(if P-34 = 0)
volume
(if P-34 0)
head 1
(if P-50 = 1)
flow
(if P-50 = 2)
if P-6 = 1
or 2, reads
20 mA
when
full empty maximum
differential
or level
full full at max.
head
or flow
if P-6 = 3
or 4, reads
20 mA
when
empty full 0
differential
or level
empty empty at 0
head
or flow
PL-443 5 – 10
