Milltronics MultiRanger Plus User Manual

cumulative
duty / backup
ratio
Relay 1 Relay 2 Relay 3 Relay 4 Relay 5
Relay Function
Fctn
P-8
Setpoints
ON OFF
Fctn
P-11
Setpoints
ON OFF
Fctn
P-14
Setpoints
ON OFF
Fctn
P-17
Setpoints
ON OFF
Fctn
P-20
Setpoints
ON OFF
Units
Alarm : Level 1 P-9 P-10 1 P-12 P-13 1 P-15 P-16 1 P-18 P-19 1 P-20 P-21 P-1
In bounds 2 " " 2 " " 2 " " 2 " " 2 " " "
Out of bounds 3 " " 3 " " 3 " " 3 " " 3 " " "
Differential 4 " " 4 " " 4 " " 4 " " 4 " " "
Rate of Change 5 " " 5 " " 5 " " 5 " " 5 " " P-1/min
Temperature 6 " " 6 " " 6 " " 6 " " 6 " " ° C
Loss of Echo 7 set P-75 7 set P-75 7 set P-75 7 set P-75 7 set P-75 n/a
Pump : LevelEn: 8* P-9 P-10 8* P-12 P-13 8* P-15 P-16 8* P-18 P-19 8* P-21 P-22 P-1
dE: 8* " " 8* " " 8* " " 8* " " 8* " " "
Ho: 8* " " 8* " " 8* " " 8* " " 8* " " "
Sequential En: 9* " " 9* " " 9* " " 9* " " 9* " " "
dE: 9* " " 9* " " 9* " " 9* " " 9* " " "
Ho: 9* " " 9* " " 9* " " 9* " " 9* " " "
En:’ 9* " " 9* " " 9* " " 9* " " 9* " " "
dE:’ 9* " " 9* " " 9* " " 9* " " 9* " " "
Ho:’ 9* " " 9* " " 9* " " 9* " " 9* " " "
En:A 9* " " 9* " " 9* " " 9* " " 9* " " "
dE:A 9* " " 9* " " 9* " " 9* " " 9* " " "
Ho:A 9* " " 9* " " 9* " " 9* " " 9* " " "
Differential En: 10* " " 10* " " 10* " " 10* " " 10* " " "
dE: 10* " " 10* " " 10* " " 10* " " 10* " " "
Ho: 10* " " 10* " " 10* " " 10* " " 10* " " "
Miscellaneous :
Totalizer 11 set P-56 11 set P-56 11 set P-56 11 set P-56 11 set P-56 vol.P-43
Flow Sampler 12 set P-57 &
P-58
12 set P-57 &
P-58
12 set P-57 &
P-58
12 set P-57 &
P-58
12 set P-57 &
P-58
volume
Time Sampler 13 set P-59 13 set P-59 13 set P-59 13 set P-59 13 set P-59 hr
Scanner n/a n/a n/a n/a n/a n/a n/a n/a 14 set P-2 n/a
RELAY PROGRAM CHART
* = Press to select LOE default ( En, dE & Ho ) and sequential option ( cumulative, duty / backup or ratio ).
