Simulation
Parameters P-76 through P-78 can be used to simulate relay operation in the program
mode. Pump relays will be held OFF during simulation, however their corresponding
LED’s will respond. Remote totalizer and flow sampler relay operation do not apply to
simulation. Refer to Parameter Description.
If the relay status can affect plant operation or personnel safety,
it is advisable to override the relay functions or disconnect the relay
wiring during calibration or simulation
Keep power disconnected at main breaker
when MultiRanger Plus cover is opened.
Relay Function Vs Mode of Operation
It should be noted that some relay functions can not be used in certain modes
of operation. The following table shows the valid functions for the five modes
of operation.
Function Mode of Operation
Mat’l Space DLD Pump Vol. OCM
(P2 = 1) (P2 = 2) (P2 = 3) (P2 = 4) (P2 = 5)
0 off off off off off
1 level level level level level
2 in bounds in bounds off in bounds in bounds
3 out of
bounds
out of
bounds
off out of
bounds
out of
bounds
4 off off differential
level
off off
5 rate rate off rate rate
6 temp. temp. temp. temp. temp.
7 L.O.E. L.O.E. L.O.E. L.O.E. L.O.E.
8 pump pump pump pump pump
9 sequential sequential off sequential sequential
10 off off pump on
differential
off off
11 off off off totalizer totalizer
12 off off off flow
sampler
flow
sampler
13 time
sampler
time
sampler
time
sampler
time
sampler
time
sampler
14 off off scanner off off
PL-443 5 – 8
