Pump Totalizer Example
Further to the Pump Control Example it is required that the volume pumped be
totalized. A daily flow total of 1,200 cubic meters is expected and a contact closure is
required every 10 cu. m. The full level of the well is equal to 42 cu.m. The following
parameters should be set.
select:
P-2 enter option "4", volume totalizer
P-17 enter option "11", relay 4-remote totalizer contact
P-33 enter option "1", estimated inflow volume is added to
pumped volume
P-37 enter "14", convert display, x14 ( 42 / 3 = 14 )
P-39 enter option "2", display low total
P-52 enter "1", totalizer convert display, totalized volume will
read as tens of cubic meters or 1 count per
10 cubic metres.
P-53 enter option "0", totalizer decimal point no decimal digits or
resolution equals 100% of a count
P-54 press "CLR"
enter "0", totalizer preset value, arbitrarily chosen
P-55 press "CLR"
enter "0", totalizer preset value, arbitrarily chosen
P-56 enter "1", totalizer contact control-closure every 10 cu. m
to re-enter run mode.
RUN
CAL
PL-443 6 – 13
