• do not prevent flow (for example, with a valve) where the chemical tube goes in the machine.
Damage will occur if a chemical supply can go in the machine when the chemical system is off.
Some configurations of components can let the chemical supplies go in the machine by a siphon
(Figure 2: Incorrect Configurations That Let the Chemical Supply Go In the Machine by a Si-
phon, page 8 ). Some can let chemical supplies go in the machine by gravity (Figure 3: Incorrect
Configurations That Let the Chemical Supply Go In the Machine by Gravity, page 9 ).
Figure 2. Incorrect Configurations That Let the Chemical Supply Go In the Machine by a Siphon
Schematic Views
Legend
P...Pump
T...Chemical tank
S...The siphon occurs above here. Liquid in the gray parts of the chemical tube and tank can go in the machine.
