MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
4.2.7 P.2
4.2.7 HEAD WASH
1
2
3
4
5
6
7
8
6. Clean inside the ink channels using washing liquid one more
time.
7. "Cap OFF” is carried out automatically and the print head
carriages move to the maintenance position. Then “Wiper ON”
is carried out automatically and the wipers are cleaned.
[ENTER]: To the next operation
8. Select the next operation.
[]: To the screen displaying the next operation
selection. (Step 9.)
[]: Filling of the transportation liquid
(Only at the factory shipment)
[]: Additional cleaning (Step 4.)
9. Select the next operation.
[]: Head-wash completed (in this sequence)
[]: Discharge of the maintenance washing liquid
(To the next operation)
10. Remove the maintenance washing liquid cartridges and
discharge the liquid inside.
11. Select [END] to end the operation.
[]: Head-wash completed (in this sequence)
[]: Discharge of the maintenance washing liquid
(Only at the factory shipment)
Set:WashingCartridges
12345678
 ABSORPTION 
00:00
Remove:Cartridges
12345678
 DISCHARGE 
00:00
Clean a wiper.
COMPLETED :ent
END < >CONTINUE
V Re-WASH
Maint.WashLiquid
END < > DISCHARGE
Remove:Maint.Wash
12345678
 DISCHARGE 
00:00
RANS Liquid
END < >ABSORB
R.1.0
Maintenance Manual > Adjustment Items > Adjustment Function > HEAD WASH
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
