MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
4.3.7 P.1
1
2
3
4
5
6
7
8
R.1.0
Maintenance Manual > Adjustment Items > Mechanical Adjustment > Positioning of the Wiper Drive Link
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
4.3.7 Positioning of the Wiper Drive Link
 Outline
 Procedure
1. After setting the clearance between the motor base and the wiper
drive link at 0.5 mm, check whether the wiper moves smoothly.
Wiper Drive Link
0.5 mm
