MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
7.1.2 P.4
7.1.2 List of Error Messages
1
2
3
4
5
6
7
8
46
 ERROR 46 
WIPER
An error occurred in wiper control. Turn off the main power, and turn it on a little later.
If the error occurs again, carry out the followings.
1. Check that the wiper sensor functions properly
with [#TEST] -> [SENSOR TEST].
2. Check that the wiper motor functions properly
with [#TEST] -> [MOTOR TEST].
3. Check whether the guide rail of the wiper is not
clogged with ink. (Does the wiper move
smoothly?)
4. Replace the wiper sensor.
5. Replace the step motor. (See 6.4.6)
6. Replace the station PCB assy. (See 6.5.6)
50
 ERROR 50 
MEDIA DETECT
Media could not be detected. Turn off the main power, and turn it on a little later.
If the error occurs again, carry out the followings.
1. Carry out [#TEST] -> [SENSOR TEST] ->
[PR SENSOR] in this order, and check whether
the PR sensor functions normally.
2. Clean the PR sensor, and adjust its mounting
position or replace it.
3. Replace the cutter slider PCB assy. (See 6.5.10)
51
 ERROR 51 
Y-ORIGIN
Y-origin could not be detected. Turn off the main power, and turn it on a little later.
If the error occurs again, carry out the followings.
1. Check that the Y-origin sensor functions
properly with [#TEST] -> [SENSOR TEST].
2. Replace the Y-origin sensor.
3. Replace the station PCB assy. (See 6.5.6)
70
E70 FPGA
FPGA Configuration fails. (This does not occur during the customer use.)
1. Replace the main PCB assy. (See 3.4.1)
71
E71 SD-RAM
Abnormal operation in SD-RAM. (This does not occur during the customer use.)
1. Make sure that PRAM PCB assy is connected
properly.
2. Replace the PRAM PCB assy. (See 6.5.3)
3. Replace the main PCB assy. (See 3.4.1)
74
E74 TRANS DATA
Received data is not Version Up file (This does not occur during the customer use.)
1. Make sure that the ROM file is transmitted.
80
E80 ROM0 ERASE
ROM0 Erase error (This does not occur during the customer use.)
1. Replace the main PCB assy. (See 3.4.1)
81
E81 ROM1 ERASE
ROM1 Erase error
82
E82 h'
ROM0 Write error
83
E83 h'
ROM1 Write error
84
E84 h'
Verify error
85
E85 ROM HASH
Hash check error
90
E90 h'
ROM Erase error
92
E92 h'
ROM Write error
95
E95 MODE SHIFT
Transition to the version up mode is not allowed.
99
E99 VERSION DATA
Wrong version data
120
 ERROR 120 
ENVIRONMENT TEMP(LO)
The ambient temperature is outside of the warranty.
(The temperature is too low.)
Adjust the ambient temperature of the printer.
Operation under the temperature among the guaran-
teed operation temperature range is recommended.
121
 ERROR 121 
ENVIRONMENT TEMP(HI)
The ambient temperature is outside of the warranty.
(The temperature is too high.)
144
 ERROR 144 
CARTRIDGE SET !
There are slots where cartridges are not inserted. Insert cartridges into the slots, since the slots may
dry up when left without them inside and the ink
may become unusable.
Give instruction (to the customers) that, when they
leave the slot without cartridge in it, its needle may
dry up and becomes unable to absorb the ink.
 List of error messages (4/6)
Error
No.
Indication on LCD Cause Remedy
R.1.3
Maintenance Manual > Troubleshooting > Details on Errors and Malfunctions > List of Error Messages
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.3
Rev.
