MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
8.3.3 P.1
1
2
3
4
5
6
7
8
R.1.2
Maintenance Manual > Operation Flow > Cut Mode > MAINTENANCE / No. COPIES
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.2
Rev.
8.3.3 MAINTENANCE / No. COPIES
Motion
FUNCTION C
MAINTENANCE <ENT>
[FUNCTION],
[] / []
MARK SENSOR
SENSOR CHECK <ent>
SENSOR CHECK
ORIGIN SET :ent
MAINTENANCE
MARK SENSOR <ent>
[FUNCTION],
[] / []
SENSOR CHECK
SIZE = 10mm
:4 to 40
SENSOR CHECK
FORM :TYPE1
:TYPE2
MARK SENSOR
POINTER OFFSET <ent>
[FUNCTION],
[] / []
POINTER OFFSET
Y = 0.0 X = 0.0
MARK SENSOR
LEVEL ADJUST <ent>
LEVEL ADJUST
OUT: 0000 IN: 0000
[FUNCTION]:Turns off the motor /
Executes initial operation
after completion.
Press [ENTER] when the value is stable.
[FUNCTION],
[] / []
SAMPLE CUT
SELECT :LOGO
SAMPLE CUT
LOGO :100%
MAINTENANCE
SAMPLE CUT <ent>
SAMPLE CUT
CUT START :ent
:1 to 999:CUT
When CUT is selected: next screen will be skipped.
[FUNCTION],
[] / []
MEDIA CUT
INTERVAL = 500mm
MEDIA CUT
FRONT CUT OFF = 30mm
MAINTENANCE
MEDIA CUT <ent>
MEDIA CUT
COUNT = 1
:0 to 9999:0 to 500:10 to 10000
TOOL REPLACE
ACTION :ent
TOOL REPLACE
COMPLETED :ent
MAINTENANCE C
TOOL REPLACE <ent>
[ENTER]:Moves the heads to the
maintenance position
and turns off the motor.
No. COPIES
COPIES = 1
No. COPIES
INTERVAL = 2mm
FUNCTION C
No. COPIES <ENT>
:0 to 30:0 to 999
[USER TYPE/TOLL]
At this point, the heads can be
moved by hand.
Perform tool change.
Move the heads with JOG key.
SENSOR CHECK
SPEED = 10cm/s
:0 to 20
[]/[ENTER]: Executes Motion 1.
[]: Executes Motion 2.
Pattern drawing
Enters REMOTE mode and
performs pattern drawing.
To LOCAL mode after
completion of initial operation.
Enters REMOTE mode and
starts operation.
STEP SIZE
SIZE = 0.025
MAINTENANCE
STEP SIZE <ent>
:0.025/0.01
[FUNCTION],
[] / []
