MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
8.5.1 P.1
1
2
3
4
5
6
7
8
R.1.0
Maintenance Manual > Operation Flow > Service Mode > #ADJUST
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
8.5.1 #ADJUST
#HEAD ADJUST
SLANT ADJUST <ent>
#SLANT ADJUST
PRINT START :ent
#HEAD ADJUST
DROP.POS ADJUST <ent>
#DROP POS. MODE
SELECT :HiSPEED SCAN
#DROP POS. MODE
SELECT :HiSPEED SCAN
:Normal-SCAN
#ADJUST / PRINT
HEAD ADJUST <ent>
#DROP POS. HsHg
SELECT :DRAFT
#DROP POS. HsHg/DRFT
ADJUST :Y Bi
#DROP POS. HsHg/DRFT
Y Bi PRINT :ent
#DROP POS. HsHg
SELECT :FINE
#DROP POS. HsHg/DRFT
ADJUST :FINE-Y Bi
#DROP POS. HsHg/DRFT
FINE-Y Bi PRINT :ent
#DROP POS. HsHg
SELECT :BASIS SET
#DROP POS. HsHg/DRFT
BASIS SET :ent
#HEAD ADJUST
HeadcondCONFIRM<ent>
#HeadcondCONFIRM
INKvolumCONFIRM<ent>
#INKvolumCONFIRM
PRINT START :ent
M= 0 M= 0 C= 0 C= 0
Y= 0 Y= 0 K= 0 K= 0
:-2 to 4
#HeadcondCONFIRM
X POS. CONFIRM <ent>
#HeadcondCONFIRM
Y POS. CONFIRM <ent>
[FUNCTION] / [] / []
[] / []
#X POS. CONFIRM
PRINT START :ent
#Y POS. CONFIRM
PRINT START :ent
[FUNCTION]: All nozzles +1
[REMOTE]: Displays the nozzle row name.
FUNCTION
#ADJUST <ENT>
[] / []
[] / []
[] / []
[] / []
[] / []
[ENTER] / [END]
#DROP POS. HsHg/DRFT
Y Bi H1 -H1 : 0.0
#DROP POS. HsHg/DRFT
Y Bi H1 -H1 : 0.0
#ADJUST / PRINT
EDGE ADJUST <ent>
[] / []
#EDGE ADJUST
CLEAR < > PRINT
#EDGE ADJUST
L=15.0 R=15.0
#ADJUST / PRINT
500mm SQUARE <ent>
#500mm SQUARE
CLEAR < > PRINT
#500mm SQUARE
X=500.0 Y=500.0
Only at the factory
[]/[]: Modifies the compensation value.
[ENTER]: Finalizes (To the next compensation screen)
Adjustment pattern
drawing
Pattern drawing
Pattern drawing
Pattern drawing
Pattern drawing
Pattern drawing
Pattern drawing
Pattern drawing
