MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
1.3.6 P.2
1.3.6 Monitoring of the Amount of Remaining Ink
1
2
3
4
5
6
7
8
(For the 6-color / 6-color + W / 8-clor ink set)
 Updating of the amount of remaining ink
The amount of remaining ink will be updated and written onto the ink IC chip at the timing shown below.
Operation
Ink consumption through one supply path [cc]
CJV30-60 CJV30-100 /
TPC-1000
CJV30-130 CJV30-160
SOFT cleaning 0.20
NORMAL cleaning 0.60
HARD cleaning 3.10
Maintenance filling 7.00
Initial filling
(No replacement)
Main suction 17.70 20.40 24.60 24.60
Initial filling
(At replacement)
Main suction 17.70 20.40 24.60 24.60
WHITE MAINTE. Lv.1 3.70
WHITE MAINTE. Lv.2 White 6.70
Color 3.70
WHITE MAINTE. Lv.3 White 12.20 12.70 15.70 15.70
Color 3.70
Spot color maintenance Color for per-
forming mainte-
nance
10.50 11.20 13.40 13.40
Other colors 3.10
No. Timing for updating Execution conditions
1 At pre-capping operation  Ink has been used for printing or flushing.
 At capping chiefly after completion of printing.
2 At completion of cleaning and filling operation  Ink has been used for cleaning and filling.
 The amount of ink remaining in the cartridge used for the
suction will be updated.
3 When any of the following events has occurred during
printing, cleaning or filling:
 Cover OPEN
 Lever UP
 Media end
 Updated by the amount of ink consumed before the occurrence
of any of the events shown at left.
4 When any of the following errors has occurred during
printing:
 Cartridge near end
 Cartridge ink end
 Cartridge error
 Updated just after occurrence of the error, not waiting for
writing at the capping pre-operation.
 Updated before replacing the cartridge during printing.
R.1.2
Maintenance Manual > Operating Principle > Ink System > Monitoring of the Amount of Remaining Ink
Model CJV30/TPC Issued 2008.08.04 Revised 2008.10.29 F/W ver. 2.50 Remark
1.2
Rev.
