Mindeo CS3290 - 9-6 RS-232 Interface

21
SETUP
Option barcode
Option
Alpha. entry
Wireless network topology for cradle※
Point coordination
Distributed coordination
00
01*
Cradle RF channel No.※
02-16
02-16
06*
Bind the first handheld unit ID※
01-16
01-16
01*
Recruit a next handheld unit ID※
01-16
01-16
Radio power level for cradle※
10dbm
7dbm
5dbm
0dbm
-5dbm
-10dbm
-15dbm
01*
02
03
04
05
06
07
Frequency hopping※
Disable
Reserved
00*
END
Show channel information of Cradle※
Note: The settings indicated with (※) are valid only when the cradle is in upgrade ready mode.
Cradle entering upgrade ready mode
Keep pressing the S button on the cradle, until the blue LED is flashing. Then three LEDs will all be
turned ON, this indicates the cradle being upgrade ready mode.
