1-2 Default setting for each barcode
Table 1-2 Default setting for each barcode
Code type
Read
enable
Check digit
verification
Check digit
transmission
Min. code
length
Proprietary
code ID
AIM
code ID
UPC-A
√
√
√
(12)
2
A
]Em
UPC-E
√
√
√
(8)
2
D
]Em
UPC-E1
√
√
√
(8)
2
D
] Em
EAN-13
√
√
√
(13)
2
A
]Em
EAN-8
√
√
√
(8)
2
C
] Em
ISBN (Bookland EAN)/ISSN
1
√
√
√
(13)
2
B
]Em
Code 39
√
-
-
1
M
]Am
Interleaved 2 of 5
√
-
-
6
I
]Im
Industrial 2 of 5
-
-
-
4
H
]Im
Matrix 2 of 5
√
-
-
6
X
]Im
Codabar
√
-
-
4
N
]Fm
Code 128
√
√
-
1
K
]Cm
UCC/EAN 128 (GS1-128)
√
√
-
1
K
]Cm
ISBT 128
√
√
-
1
K
]Cm
Code 93
√
√
-
1
L
]Gm
Code 11
-
√
-
4
V
]Hm
MSI/Plessey
-
-
-
4
O
]Mm
UK/Plessey
-
√
-
1
U
]Mm
China Post
√
-
-
(11)
2
T
]Im
China Finance
√
-
-
(10)
2
Y
-
GS1 DataBar
√
-
-
(16)
2
R
]em
GS1 DataBar Truncated
3
√
-
-
(16)
2
R
]em
GS1 DataBar Limited
√
-
-
(16)
2
R
]em
GS1 DataBar Expanded
√
-
-
1
R
]em
GS1 Composite
-
-
-
-
y
]em
PDF417
√
-
-
-
p
]Lm
MicroPDF417
-
-
-
-
p
]Lm
DataMatrix
√
-
-
-
d
]dm
QR code
√
-
-
-
q
]Qm
MicroQR code
√
-
-
-
q
]Qm
Han Xin Code
-
-
-
-
h
]Xm
Aztec Code
-
-
-
-
a
]zm
Note:
1
The settings for ISBN/ISSN and EAN-13 must be the same except the code ID.
2
Fixed-length barcodes.
3
The settings for GS1 DataBar Truncated and GS1 DataBar must be the same.
