5-33
5.4.18 Removing the Recorder
1. Open the recorder door and unscrew the two M3×6 screws.
2. Pull the two clips in the directions as indicated and meanwhile pull out the recorder.
NOTE
z Be sure not to damage the connecting cables or connectors when pulling out the
recorder.
