Mindray BeneView T8 Service Manual

6-35
6.10 New Wireless AP Package for 6800/6802
The new MPM module uses intergral parameter board (ECG ASIC).
Exploded View
Part List
SN P/N Description Qty
1 042-007507-00 Wireless AP/CF card mount 1
2 023-000505-00 Wireless router 150Mbps Wi-Fi 1
3 042-007506-00 Mounting plate for wireless LAN (ASUS) 1
4 M04-004015-
Cross recessed small pan head screw with washer
M3X8
3
5 9201-20-36109 Wireless network card spacer 1
6 9201-20-53698 Network cable 1
