Mindray BeneView T8 Service Manual

6-18
SN P/N Description Qty
14 009-000255-00 AC input connector and cable 1
15 M04-004401---
Stainless steel nut, hexagon GB/T6170-2000 M6
polished
1
16 M04-004504--- Spring washer 1
17 M04-021003--- Flat washer 1
6.6.3 Integral Module Rack
Exploded View
Parts List
SN P/N Description Qty
1
6800-20-50190 or
043-004078-00
Side plate, rear housing-ALL 1
2
6800-20-50191 or
043-004042-00
Side plate small cover, rear housing -ALL 1
3 M04-003105--- Tapping screw PT3×8 2
4 051-000243-00 6800 three-slot module rack communication board 1
5 M04-000306--- stud screw M3X10+8-8, coated with antirust nickel 2
6 M04-021024--- Large Flat Washer, GB96 3 1
7 M04-030035--- plastic stud screw M3X8+6-6 1
