5-36
6. Unscrew the two PT2×6 screws and take out the thermal printhead. Then unscrew the
two PT2×6 screws and remove the recorder’s button board.
7. Remove the recorder mounting bracket by pulling out the recorder mounting bracket
from the right side first.
Recorder mounting bracket
