Mindray BeneView T8 Service Manual

6-37
115-003227-00
6800-30-50509 Fan assembly 1
6800-20-50681 Speaker & cable 1
115-016498-00 iView assembly 1
Front housing assembly (T9)
043-003550-00 Middle frame(T9) 1
051-001516-00 LED backlight adapter board 1
021-000137-00 LCD screen, TFT, 19＂ 1
6800-30-50084 Button board 1
043-003871-00 Front bezel(T9) 1
021-000135-00 Touchscreen, resistance-type, 19″ 1
6800-30-50082 Touchscreen control board 1
115-003711-00 Encoder assembly (Optical encoder) 1
6800-30-50086 Alarm LED board 1
Front housing assembly (T8)
0000-10-10750 or
0000-10-11073(optional)
Inverter 1
021-000043-00 or
0000-10-11069 (optional)
LCD screen （only used together with optional
inverter 0000-10-11073）
1
043-000484-00 or
043-000484-01
Front bezel (T8) 1
0000-10-11071 or
0000-10-10748 (optional )
Touchscreen 1
6800-30-50082 Touchscreen control board 1
6800-30-51095(optional)
Touchscreen control board (only used together
with optional touchscreen 0000-10-10748)
1
115-001328-01
Button board(1280x1024-1+anti-glare) (without
shank)
1
115-001327-01
Button board (1280x1024-1+touchscreen )
(without shank)
1
6800-30-50086 Alarm LED board 1
6800-30-51132 Encoder assembly (without shank) 1
Front housing assembly (T6)
0000-10-10750 or
0000-10-11073(optional)
Inverter 1
0000-10-10753 or
0000-10-11068 (optional)
LCD screen （only used together with optional
inverter 0000-10-11073）
1
