5-48 Image Optimization
Parameter Description
iClear
Enhances the B mode image profile for better boundary details.
Range: Off, 1-4.
îš„ Reset Curve
Parameter Description
Reset Ori.
To reset the volume rotation, shifting and zooming to its original
status.
Reset Curve To reset the curve to its original status.
Reset All To reset the volume to its original orientation and original parameters.
îš„ Render Mode
Parameter Description
Gray/Inversion
Surface
Function: set Surface as the VR rendering mode.
This is useful for surface imaging, such as fetus face,
hand or foot.
Tip: you may have to adjust the threshold to obtain a
clear body boundary.
Max.
Function: set Max. as the VR rendering mode. Displays
the maximum echo intensity in the observation
direction.
This is useful for viewing bony structures.
Min.
Function: set Min. as the VR rendering mode. Displays
the minimum echo intensity in the observation direction.
This is useful for viewing vessels and hollow structures.
X-ray
Function: set X-ray as the VR rendering mode. Displays
the average value of all gray values in the ROI.
X Ray: used for imaging tissues with different internal
structures or tissues with tumors.
The above four rendering methods can be applied to both gray and
inversion modes.
Where inversion means to invert the grayscale of the image, so as to
enhance observation for low-echo regions, applicable for vessels,
cysts, etc.
When the function is turned on, the rendering mode parameters
change to the corresponding inverse parameters.
