2-12 System Overview
No. Name Function
<1> Pencil probe port Pencil probe port (reserved).
<2>
Mic In port
Use for connecting microphone to record vocal
comments (reserved)
<3> Two USB ports Used for connecting USB devices.
<4> ECG lead signal input
port/external ECG signal input
port
Connects to ECG leads, to directly obtain patient
electrocardiosignal/used for connecting the signal
output port of ECG monitor.
2.10 Control Panel
No. English Name Description
1.
/
Power button
Press the button to turn on the system, the system enters the
work status and the indicator becomes green.
2.
Volume Adjust the volume.
3.
/
Adjust the corresponding functions on the touch screen.
/
/
/
/
4.
TGC Slide to adjust the depth gain.
