Mindray DC-45 User Manual

System Overview 2-11
2.8 Power Supply Panel
No. Name Function
<1>
Equipotential terminal
Used for equipotential connection, balancing the
protective earth potentials between the system and other
electrical equipment.
<2> AC Auxiliary Output Power supply port for peripherals.
<3> AC Input AC power inlet.
2.9 Physiological-signal Panel
<1>
<2>
<3>
<4>
<1>
<2>
<3>
