11-4 DICOM
DICOM storage preset items are described as follows:
Name Description
Configure
New
Service
Device
After you set the server (s) in DICOM Preset screen, the
name (s) will appear in the drop-down list, select the name of
the storage server.
Service Name Default is xxx-Storage, user-changeable.
AE Title
Application Entity title, here, it should be consistent with that
of the storage server.
Port
DICOM communication port, 104 is default. Here, the port
should be consistent with that of the storage server port.
Maximum Retries Set the maximum retries.
Interval Time(s) Interval time that the system retries a connection.
Timeout
Refers to the amount of time after which the system will stop
trying to establish a connection to the service.
Compression Mode
Select the compression mode: uncompressed, RLE, JPEG,
and JPEG2000.
Compression Ratio
Select the JPEG compression ratio: lossless, low, medium,
and high.
Color Mode Select the color mode.
Allow Multiframe If SCP supports this function, then select it.
Max Frame Rate
Set the frame range of transferring cin file into DCM multi-
frame file.
SR Storage Option To enable or disenable structured reporting sending.
Add Add the DICOM service to the service list.
Cancel Click to cancel parameter setting.
Update
Select an item in the service list, change the parameters in
the above area, and click [Update] to update the item in the
service list.
Service List
Delete Click to delete the selected service in the service list.
Default
Select an item in the service list, click [Default] and you can
see “Y” in the Default column.
Verify
Click to verify if the two DICOM application entities are
normally connected.
Tips: RLE, JPEG and JPEG2000 are not supported by all SCPs. Please refer to the electronic file
DICOM CONFORMANCE STATEMENT of the SCP to check whether SCP supports or not. Do not
select these compression modes if the storage server doesn’t support them.
