Electrical Safety Inspection B-5
îš„ normal polarity( Normal Condition);
îš„ reverse polarity( Normal Condition),
îš„ normal polarity with open neutral(Single Fault Condition);
îš„ reverse polarity with open neutral(Single Fault Condition).
îš„ normal polarity with open earth(Single Fault Condition);
îš„ reverse polarity with open earth(Single Fault Condition).
LIMITS
For CF
applied parts,
 10μA in Normal Condition
 50μA in Single Fault Condition
For BF
applied parts,
 100μA in Normal Condition
 500μA in Single Fault Condition
NOTE: Make sure the safety analyzer is authorized comply with requirement of IEC60601-1.
Follow the instructions of the analyzer manufacturer.
