3-5
IBP analog output
Bandwidth 0 to 12.5 Hz (-3 dB, reference frequency: 1 Hz)
Maximum propagation Delay 55 ms (the filter function is disabled)
Sensitivity 1 V/100 mmHg ±5%
Nurse call output
Driver Relay
Electrical specifications ≤60W, ≤2A, ≤36VDC, ≤25VAC
Conducting resistance < 1Ω
Isolation voltage > 1500 VAC
Signal type Normally open or normally closed, selectable
Defibrillator synchronization pulse
Maximum time delay 35 ms (R-wave peak to leading edge of the pulse)
Amplitude 3.5 V (min) at 3 mA sourcing; 0.8 V (max) at 1 mA sinking
Pulse width 100 ms ±10%
Rising and falling time < 3 ms
VGA
Connector type 15-PIN D-sub socket
Signal RGB: 0.7 Vp-p/75Ω;
Horizontal/vertical synchronization: TTL level
3.8 ECG Specifications
Mindray DS Software Package
Lead naming style AHA, EURO
Lead fault
The lead resistance is no greater than 51 kΩ and it is in parallel with a
0.047 µF capacitor, it will not cause a lead fault condition.
For 3/5-lead, differential offsets ≤ ±300 mV, it will not cause a lead
fault condition.
Sensitivity selection
1.25 mm/mV (×0.125), 2.5 mm/mV (×0.25), 5 mm/mV (×0.5),
10 mm/mV (×1), 20 mm/mV (×2) and AUTO
Sweep speed 12.5 mm/s, 25 mm/s, 50 mm/s
Bandwidth (-3 dB)
Diagnostic mode:
0.05 to 100 Hz (812A module)
0.05 to 150 Hz (M08A module)
