Mindray MX7 Service Manual

IX
No. Symbol Description
8. S-VIDEO signal interface
VIDEO signal interface
9. AC (Alternating current)
10. Standby status indicator
11. Disk indicator
12. Battery status indicator
13. Unlocked symbol
14. Locked symbol
15. Dust-proof mesh
16. ECG function
17. Equipotentiality
18. Product serial number
19. Manufacture date
20. Manufacturer
21. Release key on the main unit
22. Main unit tray release button on the trolley
23. Maximum load bearing range of the small storage tray on
the MT3 trolley
24. Maximum load bearing range of the large storage tray on
the MT3 trolley
25. Maximum load bearing range of the main unit tray on the
MT3 trolley
26. AC output of the MT3 trolley
27. DC output of the MT3 trolley
28. MT3 trolley input

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
