Mindray MX7 Service Manual

VIII
Warning Labels
No. Warning Labels Description Position
1. Read this information
carefully before using the
system.
In the lower left corner
of the trackball
2. The following labels are
available when the system works
with the trolley.
a. Do not place the
system with the
trolley on a sloped
surface. Otherwise
the system may slide,
resulting in personal
injury or the system
malfunction. Two
people are required
to move the system
over a sloped
surface.
b. Do not sit on the
trolley.
c. When the casters are
locked, do not push
the trolley.
On the left of the trolley
panel
3 Non-ionizing radiation Bottom case of the
equipment
General Symbols
This system uses the symbols listed in the following table, and their meanings are explained as well.
No. Symbol Description
1. Type-BF applied part
2. Refer to relevant content in the Operator’s Manual, to
avoid safety accidents
3. Probe socket
4. S-VIDEO output interface
5. Network interface
6. HDMI interface
7. USB port
a
b
c

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
