Mindray MX7 Service Manual

Part I Service Scenarios
Installation 2
1 Installation
1.1 Site Preparations
1.1.1 Environment Requirement
Operational Conditions Storage and Transportation Conditions
Ambient temperature 0ºC–40ºC –20ºC to +55ºC
Relative humidity 30%–85% (no condensation) 20%–95% (no condensation)
Atmospheric pressure 700 hPa to1060 hPa 700 hPa to1060 hPa
WARNING:
Do not use this system in the conditions other than those specified.
Note:
Do not install the equipment in the following locations:
 Locations near heat generators
 Locations of high humidity
 Locations near flammable gas
1.1.2 Requirements of Power Supply
1.1.2.1 Power Supply Specifications
AC input of the main unit:
Voltage
100–240 V (adapter)
19 V DC (DC input of the main unit)
Power frequency
50/60 Hz (adapter)
Input power
2.0-1.0A (adapter)
AC input of the trolley:
Voltage
100–240 V
Power frequency
50/60 Hz
Output power
240 VA
Battery
Voltage
14.4 V (USB)

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
