Mindray MX7 Service Manual

Part II General Information
Probe and Needle-guided Bracket 146
Image Model Info Remarks
Metal:
Plastic:
Applicable Biopsy Needle
Metal: 14G, 16G, 18G,
20G, 22G
Plastic: 13G, 15G, 16G,
18G, 20G
PN(Metal)
0022-30-33012 NGB-007 NEEDLE GUIDE BRACKET
0022-30-33013 NGB-007 Needle-guided Bracket/STEEL
0022-30-33014 NGB-007 Needle-guided Bracket/STEEL
115-001757-00 NGB-007 Needle-guided Bracket/STEEL
120-001179-00 NGB-007 Needle-guided Bracket/VET
120-001180-00 NGB-007 Needle-guided Bracket/VET
120-001181-00 NGB-007 Needle-guided Bracket/VET
120-005080-00 NGB-007 Needle-guided Bracket
120-005536-00 NGB-007 Needle-guided Bracket
P/N(Plastic)
0022-30-90737 NGB-007 Needle-guided Bracket/PLAS

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
