Mindray MX7 Service Manual

Part II General Information
Field Replaceable Unit 164
No. Order Number Part Name Qty. Remark
B1
115-068074-00 Control Panel Assembly(Gray/Non-POC/FRU) 1
Include touch screen, main control
panel, silicon Overlay, Key Cap,
Encoder Knob and Key, but
without trackball
115-068075-00 Control Panel Assembly(Blue/Non-POC/FRU) 1
Include touch screen, main control
panel, silicon Overlay, Key Cap,
Encoder Knob and Key, but
without trackball
B2 115-067745-00 Kit ,Button(Non-POC/FRU) 1 With 22 key caps
B3
115-067752-00 Kit, Encoder Knob and button(Non-POC/FRU) 2 With two encoder knob and keys
043-011001-00 Kit, Encoder Knob(POC Model) 2
B4 115-067743-00 Power Button Assembly(With cable/FRU) 1
With the power button and the
connecting cable
B5
115-067744-00 Trackball Assembly(FRU) 1 For MX7 or MX8
115-068060-00 Touch Pad(POC/FRU) 1 Only for ME series
B6 049-001657-00 Silicon Overlay（FRU) 1 /
B7 115-067853-00 Control Panel PCBA(FRU) 1 Only the control panel PCBA
B8 115-068077-00 Control Panel Assembly(Blue/POC/FRU) 1
Include touch screen, main control
panel, silicon Overlay, Key Cap,
Encoder Knob and Key, touch
Control Board

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
