Mindray MX7 Service Manual

Part II General Information
Field Replaceable Unit 167
No. Order Number Part Name Qty. Remark
C1 115-067746-00 Fans Assembly(FRU) 1
C2 115-067852-00 PC Module(FRU) 1
C3 115-068057-00 Magnetic Power Socket(FRU) 1
C4 115-068058-00 S-video Interface Board(FRU) 1
C5
115-067776-00
SSD(FRU)
1
Two choice one before
shipment
115-068056-00
HDD(FRU)
1
Two choice one before
shipment
C6 115-067748-00
Kit, 4G Module
1 Optional, not yet released
C7 115-067749-00
Wi-Fi Module
1 Optional
C8 115-068053-00
Probe Board Assembly (FRU)
1
C9 115-069531-00
4D/TEE/CW Board(FRU)
1 Optional
C10 115-068055-00 Main Board Assembly(FRU) 1
C11 115-067750-00 Bottom Cover Assembly(FRU) 1
C12 115-068059-00 Dustproof Filter(FRU) 2
C13 115-067747-00 Speaker Assembly(With Cable/FRU) 1
C14 115-067751-00 Battery Chamber Cover(FRU) 1
C15 022-000412-00 AC Adapter(FRU) 1
C16 115-067777-00 Dual Probe Extend Module(FRU) 1
C17 115-068005-00 Li-ion battery(FRU) 1

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
