Mindray TE7T User Manual

Probes and Biopsy 13-23
Plastic/needle detachable needle-guided bracket:
No.
Name
Description
<1>
Support for needle-
guided bracket
Used for installing the needle-guided bracket on the probe.
<2>
Angle block
Used for determining the angle of the biopsy. There are three
angle block specifications.
<3>
Guiding block
Used for installing biopsy needles. There are five guiding
block specification for different biopsy needles.
<4>
Tab and groove for
the needle-guided
bracket
Corresponding to the tab and groove of the probe.
<5>
Guiding block
specification (13G)
Matched with the corresponding biopsy needle (13G).
<6>
Biopsy needle guiding
hole
Used for installing the biopsy needle.
<7>
Angle block
specification (60°)
The corresponding biopsy angle is 60°.
