Maximum depth at which the needle can
be detected
 Out of Plane Needle Guidance GUI:
8
Needle projection position in the
ultrasound plane
10
Projection position of the needle
guidance trajectory in the ultrasound
plane
9
Position at which the needle cross the
ultrasound plane
11
Scale of guideline (5mm/scale)
13.4.3 Preset
 NEEDLE Menu
Tap [eS.Navi] → [Image] → [NEEDLE] to enter the NEEDLE menu.
8
9
10
11
